Pressure sensor up to 400 bar / relative pressure measurement / analog output / 4 … 20mA
The simple pressure sensor PCE-PS 420 can be used everywhere where simple pressure is to be measured. The measured pressure is provided as a 4 … 20mA analog valueon the pressure sensor. With the open cable ends, the pressure sensor can be connected to a display with 4 … 20 mA input. The pressure sensoris operated with a voltage of 9-30 V DC. With the 1/4″ NPT, the pressure sensor can be connected inevery process. The measuring range extends from 2 to 400 bar relative pressure. The pressure sensor has the accuracy class 1.
– Max. 400 Bar (selectable)
– 4 … 20 mA output
– Media: non-corrosive gases and liquids
– Pressure: relative
– Diaphragm:ceramic
– Accuracy class: 1
– 4 … 20 mA output
– Media: non-corrosive gases and liquids
– Pressure: relative
– Diaphragm:ceramic
– Accuracy class: 1
Technical Specification Pressure�SensorPCE-PS 420 | |
Pressure range | 2 Bar 5 Bar 10 Bar 20 Bar 50 Bar 100 Bar 400 Bar |
General Technical Data | |
Accuracy | < ±1 % FSO (@ 10 … 40 °C) |
Zero stability | < ±2 % FSO (@ 10 … 40 °C) |
Media | Non-corrosive gases and liquids |
Temperature ranges | 0 … 60 °C |
Diaphragm | ceramic |
Load | 500 Ohm |
Analog output | 4 … 20 mA |
Power supply | 9 … 30 V DC |
Process connection (selectable) | 1/4″ NPT |
Dimensions | 30 mm x 85 mm |
Connecting cable | 4 pole ca. 1 m |
Connection assignment | Red: Power + Black: Power – White: Signal + Green: Signal – |
