– Rechargeable Li-ion battery
– ATEX II 2G EEx iad IIC T4 approved
– Easy one-button operation
– Unpumped (aspirator pump sold separately – see accessories) – Rechargeable Li-ion battery
– ATEX II 2G EEx iad IIC T4 approved
– Audible alarm: 90 dB (A)
– Visual alarm: Red and Blue LED
– Vibrational alarm
– 128 x 64 pixel LCD screen with backlight
– Event memory stores data when threshold value or limit exceeded
– Data transferrable to PC using RS-232 interface cable and software (sold separately – see accessories)
– ISO-certified calibration available for an additional fee
– Other gas sensors available (call for details)
– Used as a personal protection device by clipping the meter on the body
Technical specifications | |||
Gas | Chemical symbol | Range | Alarm limit |
Flammable gases | CH4 | 0 … 100% LEL | 20% LEL |
Hydrogen sulfide | H2S | 0 … 100 ppm | 10 ppm |
Carbon monoxide | CO | 0 … 500 ppm | 30 ppm |
Oxygen | O2 | 0 … 25% | 19% and 23.5% |
Response times (T90) | Lifespan | ||
Flammable gases | 20 s | 5 years | |
Toxic gases | 20 s | 3 years | |
Oxygen | 10 s | min. 1 year | |
Audible alarm | 90 dB (A) at 1m distance different sound for different alarm levels |
||
Visual alarm | Particularly bright LED / red and blue | ||
Display | High contrast LCD graphic display, backlit, graphical symbols for battery status with bar graph for the remaining battery operation time | ||
Power supply | Rechargeable Lithium-ion battery with 12-hour min. operating time based on pumped four-gas device with flammable gas sensor | ||
Environmental conditions | -20 … +55°C / -4 … 131° F / 0 … 99% RH non-condensing | ||
Body class | IP 65 and IP 67, can be submerged in water | ||
Dimension | 114 mm x 71 mm x 48 mm / 4.5 in x 2.8 in x 1.9 in | ||
Weight | 295 g / 10.4 oz | ||
Approval codes Europe North America |
ATEX II 2G Ex ia d IIC T4 Gb (-20 … +55°C / -4 … 131° F ), BASEEFA 05ATEX0187
CSA Class I Division 1 Groups A, B, C and D |
||
Safety standards Europe North America |
EN60079-0, EN60079-11, EN60079-1, 94/9/EC CSA22.2, 152 |
||
Calibration The device can be routinely calibrated manually using the menu, using a PC and optional Windows-compatible software (not included – see accessories) or using PCE Instruments’ recalibration services (call for details). |
