Gas Detector TCgard for CO2

Name: Gas Detector TCgard for CO2
SKU: 13408
Availability: BackOrder

TCgard-CO2

Availability : กรุณาติดต่อสอบถาม

หมวดหมู่: Gas Detector / Gas Detection Instrument

รายละเอียดเพิ่มเติม
บทวิจารณ์ (0)

Single-Gas Gas Detector warning for gases (for Carbon Dioxide CO₂), / Without display / With signal output for sensors in combination with a stationary equipment to detect gases (with ATEX approval)

Here you can find an ATEX-approved Gas Leak Detectors for flammable gases (ex), oxygen and toxic gases for fixed mounting. These Gas Leak Detectors vary by the type of gases they measure, functionality (e.g. analogue output, relay output) or the type of indicator – there are sensors with a built-in screen (as an indicator) or without. You can choose a Gas Leak Detectors for almost any type of gas: methane, propane, butane, pentane, LPG, ethanol, ethylene, nitrogen, acetylene, benzene (lead), phosphine, oxygen, ozone, carbon monoxide, carbon dioxide, hydrogen sulfide, sulfur dioxide, chlorine, ammonia (sensors for other types of gases can be requested). A Gas Leak Detector without a display (Xgard) are used in combination with an external indicator or a facility to detect gases, e.g. with the Gasmaster. Gas Leak Detectors’s that operate without internal alarm relay can be used in conjunction with the GasFlag distributor.

Gas sensors
The series of sensors Xgard, TXgard and Flamgard is always delivered calibrated and registered. By default, the sensor is delivered calibrated to methane. Please consult us for other types of calibration.
GasFlag
We offer the GasFlag for sensors without alarm relay. It is a small box for fixed installation without a display for signals for the input of 4… 20-mA. Its output has two alarm relays (max. 1 to 30V DC). The status is displayed through the LED, and it is powered to 230V.

Gasmaster
The Gasmaster is a power station of gas detection with a large display. There are several versions: 1 and 4 channels as well as with or without an interface for the PC. The Gasmater also possesses an alarm relay with which light signals or ventilators can be activated. The systems of the Gasmaster and the gas sensors are delivered configured, calibrated and verified.

– Stationary
– For Carbon Dioxide CO₂
– Additional display and alarm station
– ATEX approved

Technical Specifications for the Xgard series sensors

Gas sensor type

Xgard-Type 1

Xgard-Type 5

TCgard

EX Zone

0, 1, 2

1, 2

Types of gases to detect with corresponding measurement range
(you will find the required order code for the types of gases in the online store)

O2	0 … 25 vol%
H₂	0 … 2000 ppm 0 … 4 vol% = (100% LEL)
CO	0 … 250 ppm
H₂S	0 … 25 ppm
H₂S	0 … 25 ppm
CL₂	0 … 5 ppm
O₃	0 … 1 ppm
SO₂	0 … 10 ppm
PH₃	0 … 1 ppm
NH₃	0 … 50 ppm

0 …100 % UEG
inflammable gases
(methane, procloth, butane, pentane, LPG, ethanol, ethylene, etc.)
By default, the sensor is delivered calibrated to methane. Please consult us for other types of calibration.

Methane	0 … 100 vol%
CO₂	0 … 100 vol%
He	0 … 100 vol%

Accuracy

± 3%

±3%

Display

– – –

– – –

Signal output

2 conductors
4-mA … 20-mA

3 conductors
4-mA … 20-mA

Alarm/control relays

– – –

Norms

ATEX or UL

Power supply

8 … 30V DC / 24-mA

Temperature range

-20°C … +50°C
-4°F … +122°F

-40°C … +55°C
-40°F … +131°F

+10°C … +55°C /
+50°F … +131°F

Weight

Approx. 1 kg / 2.2 lbs

Technical Specifications of the Xgard IR series gas sensors (with infrared measuring)

Optional components for the Xgard IR	Xgard IR (infrared)	Gas sensor type
The response time of infrared gas sensors is T90 < 30 s and zero drift is approx. ± 2% per month. For highly accurate measurements and protecting the sensors exterior, there are some optional protectors. Depending on the installation site, the protector against sunlight may be the perfect option. If the sensors are mounted outside (in the open field) or in halls and pavilions that are frequently cleaned with water or disinfected from time to time, we recommend the water deflector protector. When the sensor is mounted in high humidity environments or offshore applications and vessel installations, we recommend the gas sensor with the cap resistant to rain. The cone collector is often used when you need to detect light gases (e.g. methane). This facilitates the entry of the gas into the sensor. If you have any questions, contact us: +44 ( 0 ) 2380 98703 0 Advantages to the conventional gas sensors: The great advantage of infrared gas sensors is their long life ( > 5 years) and almost inexistent long-term drift. This grealty lowers the cost of calibration. In addition, the sensors have a full temperature compensation. The ATEX, IECEx and UL norms allow them to be used worldwide.
	EX Zone	1, 2, 21 / 22
	Types of gases to detect with the corresponding range of measurement (you will find the required order code for the types of gases in the online store)	CO₂ 0 … 2 % CO₂ 0 … 5 % (according to sensor) 0 … 100% LEL inflammable gases (Methane, propane, butane, pentane, LPG, ethanol, ethylene)
	Accuracy	±2% (the whole range)
	Display	—-
	Output signal	3 conductors 4-mA … 20-mA
	Alarm / control relays	—-
	Norms	ATEX actual or UL
	Protection	IP65 / IP66 with cap resistant to inclement weather
	Power supply	10V … 30V DC / 50-mA
	Temperature range	-20ºC … +50ºC -4ºF … +122ºF
	Dimensions	156 mm x 166 mm x 111 mm / 6.1 in x 6.5 in x 4.4 in
	Weight	1 kg / 2.2 lbs (aluminium housing)

Technical Specifications of the TXgard series gas sensors

Gas sensor type

TXgard IS+

TXgard Plus

Flamgard Plus

EX Zone

0, 1, 2

1, 2

Types of gases to detect with the corresponding range of measurement
(you will find the required order code for the types of gases in the online store)

O₂	0 … 25 vol%
CO	0 … 500 ppm
H₂S	0 … 50 ppm
O₃	0 … 1 ppm
NH₃	0 … 100 ppm
Cl₂	0 … 10 ppm
H₂	0 … 2000 ppm
HCN	0 … 25 ppm
PH₃	0 … 2 ppm

O₂	0 … 25 vol%
H₂S	0 … 50 ppm
CO	0 … 500 ppm
ETO	0 … 10 ppm

0 … 100% UEG
inflammable gases
Acetylene (C2H2), ammonia (NH3), butane (C4H10), ethanol (C2H5OH), ethane (C2H6), ethylene (C2H4), hexane (C6H14), hydrogen (H2), LPG, methane (CH4), methanol (CH3OH), pentane (C5H12), steam oil, propane (C3H8), propanol (C3H8O)

Accuracy

±3%

Display

Yes

Output signal

2 conductors
4-mA … 20-mA

3 conductors
4-mA … 20-mA

Alarm / control relays

– – –

Yes

Norms

ATEX or UL

Power supply

11V … 30V DC / 20 mA

10V … 30V DC / 210 mA

10V … 30V DC / 210-mA

Temperature range

-20°C … +50°C /
-4°F … +122°F

-10°C … +55°C /
+14° F … +131°F

-10°C … +55°C /
+14°F … +131°F

Weight

0.7 kg / 1.5 lbs

2.2 kg / 4.9 lbs

Technical Specifications for the Gasflag

Warning station without display to connect one of the above sensors. This unit is usually mounted on the wall. When it exceeds the threshold value, it emits an alert tone and flashes a red alarm LED. A relay output can, for example, be connected to an omnidirectional illumination. The response time of the alarm is less than 1 sec. Threshold values can be adjusted. The alarm station is almost always used with a gas sensor. When it is not desired then the sensor itself makes the indication, and the alarm sounds.
	Sensor connection	1 sensor can be connected, 2 or 3 conductors
	Input	4-mA … 20-mA
	Output	Relay output with maximum 1 A, i.e. useful for multidirectional illumination
	Sensor connection	2 or 3 conductors / 4-mA … 20-mA
	LEDs indication	Operating availability: green LED Difficulty: amber LED Limit is exceeded: 2 red LEDs
	Display	– – –
	Operating temperature range	-20°C … +70°C / -4°F … +158°F
	Operating humidity range	0 … 99% R.H. non-condensed
	Power supply	13V … 28V DC
	Colour	RAL7035
	Housing	ABS plastic
	Dimensions	210 mm x 145 mm x 46 mm / 8.3 in x 5.7 in x 1.8 in
	Weight	0.5 kg / 1.1 lbs
	Norms	EN 50270/EMC
	Protection	IP 20

Technical Specifications for the Gasmaster (1 – 4 gas sensors)

Digital display and control panel for gas sensors described above. There are two Gasmaster models: GM 1 for a GM sensor, and 4 for up to 4 sensors (shows 4 values at one time). In addition to the standard analogue output, both types are available with an RS 232 data interface. The device also has relay outputs to activate a multidirectional light. The housing of the apparatus is protected against dust and splashing water. The unit is standard equipped with a battery so it will continue operating in case of a power failure.
Model	GM 1	GM 4
Sensors inputs	1 input for one of the gas sensors	4 inputs for 4 gas sensors
Outputs	– 1 relay output (250 VAC/8 A) – 1 analogue output (4 … 20-mA) – 1 RS 485 digital – 1 RS 232 digital -optional	– 4 relay outputs (250 VAC/8 A) – 4 analogue outputs (4 … 20-mA) – 1 RS 485 digital – 1 RS 232 digital-optional
Memory	– For 300 events (alarms, system errors, settings adjustments)
Indicators	– Digital display for gas in ppb, ppm or % -Backlight -Alarm LED, availability of uses and errors	– Digital display for 4 gases in ppb, ppm or % -Backlight -Alarm LED, availability of uses and errors
Alarm indicators	Sound: 85 dB sharp beep Visual: alarm LED
Operating temperature range	-10°C … +50°C +14°F … +122°F
Operating humidity range	0 … 95% H.r. (non-condensed)
Power supply	90V … 264 VAC / 50 Hz … 60 Hz
Battery	1.2 Ah
Housing	Steel exterior / ABS front panel
Dimensions	288 mm x 278 mm x 10 mm / 11.3 in x 10.9 in x 0.4 in
Weight	4.5 kg / 9.9 lbs
Norms	EN 50270 (EMC), EN 61010-1 low voltage
Protection	IP 54
